LR2000 Programming Manual V1.2
FNC4
{4
7B,34
123,52
"{"
{{
7B,7B
123,123
<Others> Be sure to keep spaces on both right and left sides of a bar code. (Spaces are
different depending on the types of the bar code.)
[Reference] GS H, GS f, GS h, GS w
GS r n
[Name] Transmit status
[Format] ASCII GS r n
Hex 1D 72 n
Decimal 29 114 n
[Range] n = 1, 49
[Description] Transmits the status specified by n as follows:
n
Function
1, 49
Transmits paper sensor status
[Notes]  When using a serial interface
When DTR/DSR control is selected, the printer transmits only 1 byte after
confirming the host is ready to receive data (DSR signal is SPACE). If the host
computer is not ready to receive data (DSR signal is MARK), the printer waits
until the host is ready.
When XON/XOFF control is selected, the printer transmits only 1 byte without
confirming the condition of the DSR signal.
 This command is executed when the data in the receive buffer is developed.
Therefore, there may be a time lag between receiving this command and
transmitting the status, depending on the receive buffer status.
 When Auto Status Back (ASB) is enabled using GS a, the status transmitted by GS
r and the ASB status must be differentiated using.
 The status types to be transmitted are shown below:
Paper sensor status (n = 1, 49):
Bit
Off/On
Hex
Decimal
Status for ASB
0,1
-
-
-
Undefined.
2,3
Off
00
0
Paper roll end sensor: paper adequate.
On
(0C)
(12)
Paper roll end sensor: paper near end.
4
Off
00
0
Not used. Fixed to Off.
5,6
-
-
-
Undefined.
7
Off
00
0
Not used. Fixed to Off.
Bits 2 and 3: When the paper end sensor detects a paper end, the printer goes
offline and does not execute this command. Therefore, bits 2 and 3 do
not transmit the status of paper end.
