Bematech LR2000 - GS ( K Pl Ph Cn Fn N1 N2 (Cn=49, Fn=65)

LR2000 Programming Manual V1.2
Information
Hex
Decimal
Data length (bytes)
Header
37
55
1
Identifier
2F
47
1
Width
30 - 39
48 - 57
1 to 5
Delimiter
1F
31
1
Height
30 - 39
48 - 57
1 to 5
Delimiter
1F
31
1
Fixed Value
31
49
1
Delimiter
1F
31
1
Other information
30 or 31
48 or 49
1
NUL
00
0
1
• The height and width data of the pattern are in dot units. The decimal values of the
height and width data are converted to ASCII character format and sent in order
from the MSB.
Example.: When the horizontal size is 120 dots, “120” is converted to 3 bytes
of data (Hex:31H, 32H, 30H, Decimal:49, 50, 48).
• Other information data transmission:
Hex=30H / Decimal=48 indicates that the data is printable
Hex=31H / Decimal=49 indicates that the data is not printable
GS ( k pL pH cn fn n1 n2 (cn=49, fn=65)
[Name] Set QR Code model
[Format] ASC II GS ( k pL pH cn fn n n2
Hex 1D 28 6b pL pH cn fn n1 n2
Decimal 29 40 107 pL pH cn fn n1 n2
[Range] pL = 4, pH = 0
cn = 49, fn = 65
n1 = 49, 50
n2 = 0
[Default] n1=50, n2=0
[Description] Set the QR Code model by n1.
n1 n
Function
49
Set model 1 QR code conversion
50
Set model 2 QR code conversion
