Bematech LR2000 - GS ( K Pl Ph Cn Fn N (Cn=48, Fn=68); GS ( K Pl Ph Cn Fn M N (Cn=48, Fn=69)

LR2000 Programming Manual V1.2
[Range] pL = 3, pH = 0
cn = 48, fn = 67
2 ≤ n ≤ 8
[Default] n = 3
[Description] Set to the width of the module for PDF417 to n dots
[Notes] • Settings of this function affect the processing of functions 81 and 82.
• Settings of this function are effective until ESC @ is executed, the printer is reset, or
the power is turned off.
GS ( k pL pH cn fn n (cn=48, fn=68)
[Function] Set PDF417 row height
[Format] ASCII GS ( k pL pH cn fn n
Hex 1D 28 6B pL pH cn fn n
Decimal 29 40 107 pL pH cn fn n
[Range] pL = 3, pH = 0
cn = 48, fn = 68
2 ≤ n ≤ 8
[Default] n = 3
[Description] Set row height to [n × (module width)] for PDF417.
[Notes] • Settings of this function affect the processing of functions 81 and 82.
• Settings of this function are effective until ESC @ is executed, the printer is reset, or
the power is turned off.
GS ( k pL pH cn fn m n (cn=48, fn=69)
[Function] Set PDF417 error correction level.
[Format] ASCII GS ( k pL pH cn fn m n
Hex 1D 28 6B pL pH cn fn m n
Decimal 29 40 107 pL pH cn fn m n
[Range] pL = 4, pH = 0
cn = 48, fn = 69
m = 48, 49
48 ≤ n ≤ 56 [m = 48]
1 ≤ n ≤ 40 [m = 49]
[Default] m = 49, n = 1
[Description] Set error correction level for PDF417.
m n
Function
48
The error correction level is set by “level”.
49
The error correction level is set by “ratio”. The ratio is [n x 10%]
