Bematech LR2000 - GS ( K Pl Ph Cn Fn N (Cn=48, Fn=70)

LR2000 Programming Manual V1.2
[Notes] • Settings of this function affect the processing of functions 81 and 82.
• Error correction level is specified by either “level” or “ratio.”
• Error correction level specified by “level” (m = 48) is as defined in following table The
number of the error correction codeword is fixed regardless of the number of
codeword in the data area.
n
Function
Number of error correction codeword
48
Error correction level 0
2
49
Error correction level 1
4
50
Error correction level 2
8
51
Error correction level 3
16
52
Error correction level 4
32
53
Error correction level 5
64
54
Error correction level 6
128
55
Error correction level 7
256
56
Error correction level 8
512
• Error correction level specified by “ratio” (m = 49) is defined in following table. The
error correction level is defined by [number of data codeword × n × 0.1 = (A)]. The
number of the error correction codeword changes depending on the number of
codeword in the data area.
(A)
Function
Number of error correction codeword
0-3
Error correction level 1
4
4-10
Error correction level 2
8
11-20
Error correction level 3
16
21-45
Error correction level 4
32
46-100
Error correction level 5
64
101-200
Error correction level 6
128
201-400
Error correction level 7
256
401 or more
Error correction level 8
512
• The error correction codeword is calculated by modulus 929.
• Settings of this function are effective until ESC @ is executed, the printer is reset, or
the power is turned off.
GS ( k pL pH cn fn n (cn=48, fn=70)
[Function] Select PDF417 option
[Format] ASCII GS ( k pL pH cn fn n
