Bend-Tech Dragon A400 Start-Up And Training Manual

29Bend-Tech Dragon A400
Start-Up and Training
Machine Walk Through
02
2.2.7 Gate Clamp
The Gate Clamp is used to lock the
Gate into one position. The Gate Clamp
is used only for round stock. The Gate
Clamp is critical to keeping round stock
in position during the cutting operation
of the Dragon A400. Always lock the
Gate in position with the Gate Lead
Screws in the 12 o’clock and 3 o’clock
positions.
Machines equipped with the
Powered Gate do not come
equipped with a Gate Clamp.
Front Gate
Gate Clamp
E-Stop
