Bend-Tech Dragon A400 Start-Up And Training Manual

36 Bend-Tech Dragon A400
Start-Up and Training
Machine Walk Through
02
2.5.5 Homing Sensor Designations and Locations
2.5.6 Homing Sensor Cable Connections
Homing Sensor Cable Connections should be checked to ensure they are tight and secure.
Homing Sensor Cable Connections are performed at the Bend-Tech manufacturing facility.
Homing
Sensor
Location
X Axis The X Axis Homing Sensor is located at the end of the beam
of the machine. This switch homes the Trolley on the beam.
Y Axis The Y Axis Homing Sensor is located at the Left rear of the
Trolley, just in front of the Chuck Drive Gear. This switch
homes the Chuck.
Z Axis The Z Axis Homing Sensor is located on the right-hand side
of the Toolhead mount. This switch homes the Toolhead on
its horizontal axis.
A Axis The A Axis Homing Sensor is located at the top of the
Toolhead mount on the front of the machine. The machine
uses to the A Axis homing sensor to home the Toolhead on
its vertical axis.
B Axis The B Axis Homing Sensor is located inside the Material
Support Lift housing under the Material Support Lift collar
sleeve. This switch homes the Material Support Lift.
C Axis The Homing Sensor for the C Axis is located on the C Axis
Motor mounting bracket on the left side of the front of the
machine. This switch homes the Gate.
Do not use tools to tighten cable connectors. Tightening cable connectors with tools
can damage them and aect the performance of the machine.
