Bend-Tech Dragon A400 Start-Up And Training Manual

47Bend-Tech Dragon A400
Start-Up and Training
Machine Control Startup
03
3.3.7 Machine Control
At the top of the screen, click Machine Control.
Click the down arrow next to the Machine Selection window. Select the
Dragon A400 name the Operator created in 3.3.6.
Click OK. Mach3 software will open at this time.
3.3.8 Mach3 Machine Control
Mach3 CNC software control interface will appear. The Operator will primarily work in the
Bend-Tech Machine Control interface when operating the Dragon A400.
In some cases, if there is only one machine entered in the Machine Library, the
program may go straight to Mach3 and not present a Machine Selection window after
clicking Machine Control.
If Mach3 does not connect properly repeat Power On Dragon A400 Control Box
procedure beginning at Section 3.3.
Machine Control interface Mach3 CNC Machine Control interface
