1.3 Trolley
The Dragon A400 uses the Trolley to position the material during the machine’s cutting
process. Ensuring the Trolley is assembled correctly, and is mounted on the Rail correctly, is
critical to the operation of the machine.
1.3.1 Trolley Cover
In order to inspect for proper Trolley motor and sensor cable connections, the Trolley Cover
must be removed. This requires removing the 16 screws that secure the cover to the Trolley.
This also requires disassembling the E-stop switch located on the Trolley Cover.
Aligning the Rail Splices is one of the most dicult and time-consuming parts of the
assembly process. Ensuring Rail Splices are straight and even is critical to the setup
of the Dragon A400. Bend-Tech recommends experienced personnel perform the Rail
Splice installation.
The Dragon A400 is shipped with the Trolley Cover separate from the Trolley. Bend-
Tech recommends leaving the Trolley Cover o the machine in order to conduct initial
machine inspection. However, in some cases, the inspection will require Trolley Cover
removal.
9Bend-Tech Dragon A400
Start-Up and Training
Setup Inspection
