19Bend-Tech Dragon A400
Assembly Manual
Beginning Assembly
03
3.6 Rail and Rail Beam Sections
Cut the metal strapping and remove
the Rail Beam sections. Locate the
Rail Beam section with a “5” sticker
and a “4” sticker. Locate the No. 4
Rail Support Leg and remove it from
the crate.
A wrench may be needed to thread the Swivel Levelers into the bottom of the Rail
Support Legs.
Customers who ordered the 12-foot model will not receive an additional Rail Support
Leg.
Installing the Swivel Levelers may require a helper to lift the Tail assembly to access
the threaded inserts on the bottom of the support legs.
