Bend-Tech Dragon A400 - Torch; Torch Cable; Torch Ground

41Bend-Tech Dragon A400
Assembly Manual
Torch
08
08
Torch
8.1 Torch Cable
The Installer should have attached the Torch cable
to the Control Box as outlined in Chapter 5, section
5.5. Connect the loose end of the Torch Cable
to the power cable connection at the back of the
Hypertherm unit.
8.1.1 Torch Ground
Connect the alligator clamp from the Hypertherm
unit to the ground cable on the Dragon A400.
Tools Needed
• 
• Phillips Screwdriver
Alligator Clamp
Ground Cable
