53Bend-Tech Dragon A400
Assembly Manual
Mounting to the Floor
10
10.4 Install Concrete Sleeve Anchors
Ensure the Floor Brackets have been re-installed on the Rail Support Legs. Do not tighten.
With the Floor Brackets loose, insert a concrete anchor sleeve into the drilled holes.
sleeve anchor is snug to the Floor Bracket.
Floor Bracket to the Rail Beam Support Leg.
Sleeve Anchor
Installing concrete sleeve anchors requires the use of a hammer drill.
