27Bend-Tech Dragon A400
Assembly Manual
Drive Belt Installation
04
04
Drive Belt Installation
4.1 Drive Belt Pre-Installation
The Dragon A400 is delivered with the Drive Belt mounted on the Head of the machine. The
Drive Belt is pre-installed around the Drive Belt Pulley and the idler pulleys located on the
Trolley. Since the machine is a modular design, the Drive Belt has been disconnected from the
Tail of the machine after factory assembly and calibration. It has been rolled up and shrink-
wrapped for shipping purposes.
4.2 Installing the Drive Belt
Before installing the Drive Belt the Installer should remove any shrink wrap and/or
plastic banding securing the Trolley.
Tools Needed
•
• Belt tensioning tool (provided)
