39Bend-Tech Dragon A400
Assembly Manual
Air Line
07
07
Air Line
7.1 Air Line Connection Overview
The Dragon A400 requires two air line feeds. One air line is connected to the air inlet on the
Control Box. A second air line is connected to the Hypertherm.
It is recommended that the air supply to the Dragon A400 be equipped with an air
water separator and lter.
Control Box Air
Connection
Air Line to
Compressor
T-Fitting
Hypertherm Air
Connection
