37Bend-Tech Dragon A400

Assembly Manual

Trolley

6.2.5 Rear Plate

Place the Rear Plate on the Chuck Cover. The back of the Chuck assembly will protrude

through the Rear Plate. Fasten the Rear Plate to the Chuck Cover using the hardware supplied



Ensure the wires for the E-Stop switch are routed clear of any moving parts within the

Trolley Cover.

E-Stop Switch

Chuck Key Housing

Rear Plate
