20 Bend-Tech Dragon A400
Assembly Manual
Beginning Assembly
03
3.6.1 Installing Rail Beam Sections

Rail Beams, slide the No.5 end of the 4/5 Rail Beam into the No. 5 end of the Rear Tail section.
Set the No. 4 end of the 4/5 Rail Beam on the No. 4 Rail Support Leg.
With the Swivel Levelers attached to the No. 4 Rail Support Leg it will be necessary to
enlist a helper to install the No. 4/5 Rail section.
54
If necessary, use a rubber mallet or a plastic dead blow hammer to tap the rails into
place.
Tools Needed
Rubber mallet or plastic dead blow hammer
