4.2.2.2 Cavity wall and panel mounting
For cavity wall or panel mounting you will need a "Complete mounting kit"
(Art. No.
B95101000)
.
4.2.2.3 Mounting brackets
By means of the mounting brackets (attached on each side) the MK2430 snaps into the
flush-mounting enclosure. Two mounting brackets (M) are used for additional support.
They are needed in particular if the MK2430 has to be fixed into an existing flush-mounting
enclosure (e.g. MK2418) which is not intended for snap-on mounting. The "Complete
mounting kit (Art. No. B95101000)" is required for this.
Cavity wall mounting
Panel mounting
