Bender COMTRAXX MK2430 User Manual

Technical data
78
MK2430_D00129_02_M_XXEN/09.2019
Connection properties (inputs)
Connection of single conductors:
rigid/flexible/conductor sizes ................................................0.08…1.5/0.08…1.5 mm
2
/AWG 28-16
flexible with ferrules, without/with plastic sleeve* .................................. 0.25…1.5/0.25…0.5 mm
2
Multi-conductor connection (2 conductors with the same cross section):
rigid/flexible ............................................................................................. 0.08…0.5/0.08…0.75 mm
2
flexible with ferrule without plastic sleeve................................................................... 0.25…0.34 mm
2
flexible with TWIN ferrule with plastic sleeve ..............................................................................0.5 mm
2
Stripping length................................................................................................................................. 7 mm
Tightening torque....................................................................................0.5…0.6 Nm (4.5…5.3 lb-in)
Other
Operating mode ....................................................................................................... continuous operation
Mounting.......................................................................................................................... display-oriented
Degree of protection, internal components (DIN EN 60529)...........IP50 (surface-mounting type: IP54)
Degree of protection, terminals (DIN EN 60529).................................................................................IP20
Flammability class........................................................................................................................ UL94V-0
Weight
Flush-mounting type .................................................................................................................... ≤ 210 g
Surface-mounting type.................................................................................................................
≤ 400 g
*For MK2430H-12 (B95100024) no ferrules with plastic sleeves may be used!
9.1.1 Standards, approvals and certifications
The MK2430 alarm indicator and test combination meets the requirements of the
regulations for installation IEC 60364-7-710:2002-11 and DIN VDE 0100-710 (VDE 0100
Part 710).
