Operation
51
MK2430_D00129_02_M_XXEN/09.2019
7.2.3 Test function
Press and hold down the "TEST" button for at least one second to check the function of
the assigned insulation monitoring devices (e.g. isoMED427P, 107TD47, IRDH…), LIM
(Line Isolation Monitors) and GFCI (Ground Fault Circuit Interrupters). A message will
only be displayed on the MK2430 on which the "TEST" button has been pressed.
1. Test all devices Tests all devices set in the "Test addresses" menu.
2. Test single device Select a device using the arrow buttons and press
the "↵" button.
During the test the status line displays "TEST". The message "TEST" flashes if the
message being displayed has been caused by the test.
The assigned devices are tested one after another. The MK2430 automatically evaluates
the messages that appear. Once the process is completed, either a common message
about a successful test or an error message is displayed.
If more than one device has been tested, a separate error code will be displayed for each
device failing the test.
The display may deviate depending on user-defined messages.
If messages are pending and one of the arrow buttons is pressed, the latest
message will appear on the display. If no further button is pressed, this
message will be displayed for 15 seconds.
1.Test all devices
2.Test single device
1.Test all devices
2.Test single device
Addr.: 3 (01/02)
107TD47
