Operation
50
MK2430_D00129_02_M_XXEN/09.2019
– Line 4 Status line
xx = Consecutive number of message displayed
yy = Number of pending messages
= Message text page, in this case page 1
zzz = Insulation fault location or test in progress (refer to table)
09:50 = Time (example)
Possible displays during insulation fault location or testing:
Press the " " button (6) to receive further information.
– Line 1: Date and time the message occurred
– Line 2: Device triggering the message
– Line 3: Address and channel of device triggering the message
– Line 4 xx = number of the message displayed
yy = number of pending messages
= alarm test page, in this case page 2
17:30 = time of day (example)
zzz Meaning
EDSa EDS insulation fault location in progress (automatic).
EDSp Continuous EDS insulation fault location in progress.
EDSs Single-pass EDS fault location in progress.
EDS
EDS insulation fault location was deactivated, the current test pro-
cedure is still running.
TEST
Test is running. The message "TEST" flashes if the message being
displayed has been caused by the test.
noMA No master
MAST Device is currently "substitute master".
Since: 01.05.12 16:52
Device: Isometer
Addr/channel: 003/00
xx/yy [ ] 17:30
