Commissioning and testing
39
MK2430_D00129_02_M_XXEN/09.2019
5.2 Tests after switching on
5.3 Parameter setting
All settings can be carried out via the TMK-SET software. Alternatively, the
basic settings can be carried out via the MK2430 menu (see diagrams).
Check the supply voltage
of MK2430 (terminals U2,
V2). Voltage OK?
no
Make corrections. If
required, connect another
or different power supply
unit for MK2430 supply.
Did the supply voltage or
the MK2430 fail?- Remove
the fault.
yes
Fix the MK2430 to the
enclosure.
Does the MK2430 display
a fault message?
Make a note of the
message. Adapt the
indicating device to the
system or remove the fault.
Does anything appear on
the MK2430 display?
no
yes
yes
Connect a PC utilizing TMK-
SET software. Activate the
TMK-SET function "Bus
scanning". Are addresses
and software versions of
connected devices OK?
no
Make corrections
yes
Set MK2430 parameters
no
To Next Page
