Menu mode: Operation and setting
71
MK2430_D00129_02_M_XXEN/09.2019
8.4.4.3 Control menu 3: EDS Start/Stop
Press "" to manually start and stop the EDS system test procedure. This function can
only be activated for the master. The current status appears in the last line.
EDS system runningOnce started, the EDS4xx-12 and PGH47x run continuously. If you
exit the menu, the standard display "EDSp" will appear in
the last line in order to indicate continuous running
*
.
EDS system stop Stops the continuous running of EDS4xx-12 and PGH47x.
If you exit the menu, the standard display "EDS" will
appear in the last line until the current test run finishes.
*
Other abbreviations that might appear in the last line of the display:
EDSa Automatic mode: Insulation fault location has been
started on PGH47x by e.g. ISOMETER®, ATICS® or
isoMED427P.
EDSs Single mode: A single run has been started by IN2 on
PGH471.
8.4.4.4 Control menu 4: Test communication (MK2430-11 only)
Testing the communication via the BMS bus. For this purpose, an error message is
simulated on a digital input. This fault message is sent to evaluating devices (such as
MK…, TM…, SMO…) via the BMS bus. Check that these devices are responding to the
fault message as requested.
Channel 003 Setting the channel whose message is to be activated.
1.Exit
2.Reset (AlarmClear)
3.EDS start/stop
EDS system running
1.Exit
2.Reset (AlarmClear)
3.EDS start/stop
EDS system stop
1.Exit
2.Channel: 003
-Test communication-
