Operation
48
MK2430_D00129_02_M_XXEN/09.2019
The buttons have the following functions:
No. In operating mode In menu mode
5
" " button (mute button);
Set buzzer to mute after an alarm/
acknowledge alarm.
"ESC" button;
Exit function (without saving)
or go up one menu level.
When the buzzer is activated, the ESC
button will mute the buzzer.
6
" " button (additional text);
Toggle between display text and addi-
tional alarm text (if available).
Arrow button "
▼";
to go down in the menu.
7
" " button (scroll);
Scroll through the warnings and alarms
if there is more than one message pend-
ing.
Arrow button "
▲";
to go up in the menu.
8
"TEST" button;
Press and release: LED test;
Press and hold: Trigger the test of
assigned devices (insulation monitoring
devices, LIM, GFCI).
No function.
9
"MENU" button;
Starts menu mode for setting the
MK2430;
for display and control functions.
"↵" button (ENTER button);
To confirm the selected menu item.
