Menu mode: Operation and setting
63
MK2430_D00129_02_M_XXEN/09.2019
Specific alarm messages
These messages contain details about medical gases and BSV systems.
Neutral and specific alarm messages
Alarm messages for medical gases are signalled by the red "ALARM" LED
and the sound of the buzzer. The buzzer can be set to mute (acknowl-
edged). The buzzer sounds again after 15 minutes as a reminder.
Different settings can only be made using the TMK-SET software.
Inputs
Neutral
alarm messages
"Function: neutral"
Specific alarm messages
"Function: medical"
IN1 Alarm: Address/channelXXX/01 Alarm: Oxygen
IN2 Alarm: Address/channel XXX/02 Alarm: Vacuum
IN3 Alarm: Address/channel XXX/03 Alarm: Nitrous oxide
IN4 Alarm: Address/channel XXX/04 Alarm: Compressed air 5 bar
IN5 Alarm: Address/channel XXX/05 Alarm: Compressed air 8 bar
IN6 Alarm: Address/channel XXX/06 Alarm: Nitrogen
IN7 Alarm: Address/channel XXX/07 Alarm: CO2
IN8 Alarm: Address/channel XXX/08 Alarm: BSV battery operation
IN9 Alarm: Address/channel XXX/09 Alarm: BSV overload
IN10 Alarm: Address/channel XXX/10 Alarm: BSV converter failure
IN11 Alarm: Address/channel XXX/11 Alarm: BSV fault
IN12 Alarm: Address/channel XXX/12 Alarm: BSV test run
