Settings
55
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
Set the function for the outputs:
8.2 (2.4.2.1.4) Function 2
See chapter 8.2 (2.4.2.1.3) "Function 1”.
8.2 (2.4.2.1.5) Function 3
See chapter 8.2 (2.4.2.1.3) "Function 1”.
8.2 (2.4.2.2) Channel relay
Select the relay you want to set.
Submenues see chapter 8.2 (2.4.2.1) "Common relay” (2.4.2.1.1) to (2.4.2.1.5)
8.2 (2.4.2.3) Buzzer
Select the buzzers to be configured.
Afterwards, assign the selected buzzers to the events on which they should trip.
8.2 (2.4.2.3.1) TEST
See chapter 8.2 (2.4.2.1.1) "TEST”.
•off The function is not used.
•I
ΔL
The status of the output changes if an insulation fault is detected
(EDS function) on one of the measuring channels.
•I
ΔN
The status of the output changes if the residual current
(RCM function) is exceeded.
•Device error The status of the output changes in the event of an internal
device error.
•Connection fault The status of the output changes if one of the following measu-
ring current transformer connection faults occurs:
• Measuring current transformer defective
• Power supply cable interrupted
• Power supply cable short-circuited
•Common alarm The status of the output changes on the occurrence of any
alarms and fault messages (I
∆L
alarm, I
∆n
alarm, connection and
device error).
•Relay 1 (BS 2/1)
...
•Select all All buzzers are selected.
•No selection No buzzer is selected.
•Invert selection The current selection is inverted.
•Buzzer 1 (BS 2/1) A single buzzer is selected.
