Installation and Settings
38 / 64
Figure 65 WLAN Settings
Note
：
When the equipment is in Router Mode, need to add WAN settings.
Select DHCP Connection Mode
：
The port attains
IP address automatically, DNS is
attained
vi
a
DHCP
server
in
default,
i
f
th
ere
is
no
special
requirement,
no
need
to
set.
Select
Sta
tic
Config
uration
Co
nnection Mode,
configure
IP address
and
DN
S
statically, as shown in the figure below:
Figure 66 WLAN Settings Example 1
47
