6 Appendix
59 / 64
6 Appendix
6.1 Technical Parameters
Table 6
Item Description
2 x Ethernet
ports of 10/100M
1 x Main port
1 x Auxiliary port
Port
Support PoE
Power Supply
Power Supp
ly Indicator
3 level Sign
al Strength Indicator
Indicator
LAN Indicator
Frequency
BXM2：2.4
1
2–2.462GHz
BXM5：5.740GHz -5.840GHz
Standard
BXM2:IEEE 802.11b/g/n standard
BXM5:IEEE 802.11a/n standard
Tx Power
BXM2:max 25.3dBm(340 mW), adjust software to reach
BXM5:max 18.4dBm(68mW), max, power
Speed Rate 2x2 max, speed rate: 300Mbps
Modulation
Technology
802.11n：2x
2 MIMO
BXM2: 802.11b，
1Mbps：-100dBm
801.11g，6Mbps：-93dBm
801.11n，MSC0:-93dBm；MSC0:-74dBm
Receiving
Sensibility
BXM5: 802.11a，
6Mbps: -95dBm；54Mbps：-75dBm
801.11n，MCS0：-88dBm；MCS7：-73dBm
Antenna
BXM2:dual
-
polarization 11dBi, horizontal beam 65°,
vertical beam 30°。
BXM5：dual-polarization 16dBi, horizontal beam 60°,
vertical beam 15°。
Reset/Resume
Support
