11.4 Monitoring

This menu is used to monitor your WLAN infrastructure.

Note

In order to ensure adequate timing between the WLAN Controller and the connected

Slave APs, the internal time server of the WLAN Controller should be enabled.

bintec elmeg GmbH

11 Wireless LAN Controller

bintec RS Series 195
