Field Description
• *- 5%1 E1: The TOS value is specified in decimal
format, e.g. 63.
• *- ?>%1 E1: The TOS value is specified in
hexadecimal format, e.g. 3F.
COS Filter
(802.1p/Layer 2)
Enter the service class of the IP packets (Class of Service,
CoS).
Value range  to ,.
The default value is .
12.4.2 QoS Classification
The data traffic is classified in the Networking->QoS->QoS Classification menu, i.e. the
data traffic is associated using class IDs of various classes. To do this, create class plans
for classifying IP packets based on pre-defined IP filters. Each class plan is associated to
at least one interface via its first filter.
12.4.2.1 New
Choose the New button to create additional data classes.
Fig. 96: Networking->QoS->QoS Classification->New
The Networking->QoS->QoS Classification->New menu consists of the following fields:
