Field Description
wireless connection.
Values:
• > 25 dB excellent
• 15 – 25 dB good
• 2 – 15 dB borderline
• 0 – 2 dB bad.
Data Rate mbps Shows the current transmission rate of data received by this cli-
ent in mbps. The following clock rates are possible: IEEE
802.11b: 11, 5.5, 2 and 1 mbps; IEEE 802.11g/a: 54, 48, 36, 24,
18, 12, 9.6 Mbps. If the 5-GHz frequency band is used, the in-
dication of 11, 5.5, 2 and 1 Mbps is suppressed for IEEE
802.11b.
Rate Displays the possible data rates on the wireless module.
Tx Packets Shows the number of sent packets for the data rate.
Rx Packets Shows the number of received packets for the data rate.
22.5.3 Client Links
In the Monitoring->WLAN->Client Links menu, current values and activities of the con-
figured client links are displayed.
Fig. 215: Monitoring->WLAN->Client Links
Values in the Client Links list
Field Description
Client Link Description Shows the name of the client link.
AP MAC Address Shows the MAC address of the client link partner.
Uptime Shows the time in hours, minutes and seconds for which the cli-
ent link in question is active.
bintec elmeg GmbH
22 Monitoring
bintec RS Series 521
