Field Description
• 3 @#: Enter an IP address range with a start and
end address.
Address / Subnet Only for Address Type = 3 / "
Enter the IP address of the host or a network address and the
related netmask.
The default value is .
Address Range Only for Address Type = 3 @#
Enter the start and end IP address of the range.
17.3.2 Groups
A list of all configured address groups is displayed in the Firewall->Addresses->Groups
menu.
You can group together addresses. This makes it easier to configure firewall rules.
17.3.2.1 New
Choose the New button to set up additional address groups.
Fig. 148: Firewall->Addresses->Groups->New
The menu Firewall->Addresses->Groups->New consists of the following fields:
Fields in the Basic Parameters menu.
Field Description
Description Enter the desired description of the address group.
bintec elmeg GmbH
17 Firewall
bintec RS Series 393
