Chapter 6 Assistants

The Assistants menu offers step-by-step instructions for the following basic configuration

tasks:

• First steps

• Internet Access

• VPN

• Wireless LAN

• VoIP PBX in LAN

Choose the corresponding task from the navigation bar and follow the instructions and ex-

planations on the separate pages of the Wizard.
