Field Description
dress/Netmask corresponding netmask.
Destination Port/Range Only for Protocol = *6 or .5
Enter a destination port number or a range of destination port
numbers.
Possible values:
• 311 (default value): The destination port is not specified.
• +%$( +: Enter a destination port.
• +%$( + #: Enter a destination port range.
Source IP Address/
Netmask
Enter the source IP address of the data packets and the corres-
ponding netmask.
Source Port/Range
Only for Protocol = *6 or .5
Enter a source port number or a range of source port numbers.
Possible values:
• 311 (default value): The destination port is not specified.
• +%$( +: Enter a destination port.
• +%$( + #: Enter a destination port range.
DSCP/TOS Filter
(Layer 3)
Select the Type of Service (TOS).
Possible values:
• # (default value): The type of service is ignored.
• 56 :( E1: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in binary format, 6 bit).
• 56 5%1 E1: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in decimal format).
• 56 ?>%1 E1: Differentiated Services Code
Point according to RFC 3260 is used to signal the priority of
IP packets (indicated in hexadecimal format).
• *- :( E1: The TOS value is specified in binary
format, e.g. 00111111.
