Fig. 113: Multicast->IGMP->Options
The Multicast->IGMP->Options menu consists of the following fields:
Fields in the Basic Settings menu.
Field Description
IGMP Status Select the IGMP status.
Possible values:
• 3 (default value): Multicast is activated automatically for
hosts if the hosts open applications that use multicast.
• .+: Multicast is always on.
• 57: Multicast is always off.
Mode Only for IGMP Status = .+ or 3
Select Multicast Mode.
Possible values:
• 6+"1( ' (default value): The router uses IG-
MP version 3. If it notices a lower version in the network, it
uses the lowest version it could detect.
• E & 1(: Only IGMP version 3 is used.
Maximum Groups Enter the maximum number of groups to be permitted, both in-
ternally and in reports.
The default value is .
Maximum Sources Enter the maximum number of sources that are specified in ver-
sion 3 reports and the maximum number of internally managed
14 Multicast bintec elmeg GmbH
274 bintec RS Series
