Fig. 185: Local Services->Wake-On-LAN->WOL Rules->New
The Local Services->Wake-On-LAN->WOL Rules->New menu consists of the following
fields:
Fields in the menu Basic Parameters
Field Description
Wake-On-LAN Rule
Chain
Select whether to create a new rule chain or to edit an existing
one.
Possible values:
• )7 (default value): You can create a new rule chain with this
setting.
• A) $ 1 %B: Shows a rule chain that has
already been created, which you can select and edit.
Description
Only where Wake-On-LAN Rule Chain = )7
Enter the name of the rule chain.
Wake-On-LAN Filter
Select a WOL filter.
If the rule chain is new, select the filter to be set at the first point
of the rule chain.
If the rule chain already exists, select the filter to be attached to
the rule chain.
To select a filter, at least one filter must be configured in the
19 Local Services bintec elmeg GmbH
472 bintec RS Series
