Clinician's Guide
7. Tighten side straps on lower abdominal support.
8. Adjust side vertical straps, if necessary.
9. Wrap leg supports around the upper thigh and secure the Velcro
®
.
10. Adjust side vertical straps attached to the leg supports, if necessary.
11. Adjust shoulder straps to the desired length.
Figure 3-1: Patient Harness Features
Shoulder Straps
Lower Abdominal Support
Upper Abdominal Support
Top Torso Support
Side Straps
Side Vertical Straps
Side Vertical Leg Straps
Leg Supports
D-Ring
< 500 lbs. (227 kgs.)
< 400 lbs. (182 kgs.)
