Rev. 3.1 7. RESPIRATION 131
BM5 (CS,CX) User’s Manual
7.1 Outline
Respiration via ECG Lead II electrode makes the skin area of the chest enlarged, causing changes
in the resistance of skin. Through this it calculates respiration value per minutes and performs the
alarm function according to limit value.
Position of
Detected
Lead II
Position of
Detected
Lead I
