Rev 3.1 9. IBP 153
BM5 (CS,CX) User’s Manual
9.3 IBP Data Setting
Labels for measuring positions are described on each menu.
CHANGE NAME: Menu to set measuring position
SCALE: Menu to set size of measurement waveform on screen.
LIMITS: Menu to set alarming range.
SETTING: Menu for processing various pressure signals.
ZERO: Menu to set zero-point of Transducer.
UNIT SELECT : Menu to unit change.
SETTINGZERO
CHANGE
NAME
:ART
SCALE:
160
ALARM
MAIN
MENU
CHANGE NAME (Setting Measuring Position)
It performs the name changing function for a measuring position to monitor.
The setting positions are ART, FEM, PAP, RAP, LAP, UAP, UVP, CVP, ICP and OTHER.
SETTINGZERO
CHANGE
NAME
:ART
SCALE:
160
ALARM
MAIN
MENU
> ART UAP
FEM UVP
PAP CVP
RAP ICP
LAP BP1
CHANGE
NAME
:ART
MAIN
MENU
To Next Page
