Bionet BM5 - ECG Data Setup and Analysis

Rev. 3.1 5.ECG 99
BM5 (CS,CX) User’s Manual
5.3 ECG Data Setup
A setup window appears at lower part of the screen when the Trim Knob Key is pressed in the ECG
Parameter Window. Selection is made by pressing the Trim Knob Key, while movement across the
menu is performed by turning the key either clock or anticlockwise.
PREV
MENU
MAIN
MENU
ANALYSIS
SETTING
12LEAD
ECG
ANALYSIS
LEAD
SELECT
ALARM
LIMIT
QRS
VOLUME :
OFF
DISPLAY
LEAD SELECT
Select channels from I to V in ECG
Lead I, II, III show up in case of connecting 3-Leads ECG Cable.
Lead I, II, III, aVR, aVL, aVF, V show up in case of connecting 5-Leads ECG Cable.
Lead I, II, III, aVR, aVL, aVF, V1,V2,V3,V4,V5,V6 show up in case of connecting 10-Leads ECG
Cable.
PREV
MENU
MAIN
MENU
ANALYSIS
SETTING
12LEAD
ECG
ANALYSIS
LEAD
SELECT
ALARM
LIMIT
QRS
VOLUME :
OFF
DISPLAY
TRACE I :
I
TRACE II :
II
PREV
MENU
MAIN
MENU
LEAD 1 SELECT MENU
TRACE I :
I
TRACE II :
II
PREV
MENU
MAIN
MENU
