BM5 (CS,CX) User’s Manual
1.6 Battery Power Supply Application
Battery power can be supplied for enabling a portable use or a use during DC power failure.
Operation
1. Battery Power LED is lighted on when the machine is in use.
2. The DC/battery power is only sustainable for 1 hour.
3. Battery is automatically charged when the machine is connected
to
DC Power Supply. Battery LED is lighted on after blinking.
4. The charging status of the batteries is displayed with 5 green boxes, each indicating a different
charging
. ( 0% -> 25% -> 50% -> 75% -> 100%)
Battery: ICR18605 22F-031PpTC (10.8V - 2200mA, Li-ion)
The Lithium-Ion battery is a rechargeable battery containing Lithium-Ion cells. Each battery contains
an integrated electronic fuel gauge and a safety protection circuit.
5. The discharge condition of battery is indicated with on of 5 yellow boxes, each box showing a
different level of charge available.
.
