Rev. 3.1 6.SpO2
BM5 (CS,CX) User’s Manual
6.3 SpO
2
Data Setup
ALARM LIMIT： Menu in which SpO
2
limits are set up.
SWEEP SPEED: speed SpO2 Waveform display setting menu
RATE VOLUME：Menu in which RATE VOLUME is set up
ALARM
RATE
VOLUME:
OFF
MAIN
MENU
RATE VOLUME
Move the KEY to select the volume from OFF to 100%.
When the ECG volume rate is set, it turns OFF automatically.
ALARM
RATE
VOLUME:
OFF
MAIN
MENU
> OFF 60%
10% 70%
20% 80%
30% 90%
40% 100%
50%
RATE
VOLUME:
OFF
MAIN
MENU
ALARM
Two menus: ALARM LIMIT, ALARM provided in the alarm menu
Number setting of alarm value of %SpO2 is 0 ~ 100
Warning sound or message displays configuration menu when an alarm is triggered.
1. Move the ▶ mark to select from RETURN, SpO2 or SpO2-R, and press.
2. After pressing at SpO2, move the cursor right or left to LOW, and press.
3. Once the color is changed, move the cursor again to the selected value and press.
