Rev. 3.1 8. NIBP 142
BM5 (CS,CX) User’s Manual
8.3 NIBP Data Setup
ALARM： A menu to set the Alarm
STAT: A menu to start 5 minutes of continuous, sequential NIBP measurements.
CUFF SIZE：A menu to select cuff size
UNIT SELECT: A menu to select the pressure unit
INTERVAL ：A menu to set Interval time when measures the blood pressure periodically
INFLATION: Initial Pressurization setting menu
INTERVAL:
OFF
INFLATION:
170mmHg
UNIT
SELECT:
mmHg
ALARM
NIBP
STAT:
OFF
CUFF
SIZE:
ADT
MAIN
MENU
ALARM
The alarm provides ALARM LIMIT and ALARM SOUND.
Alarm setting Numeric Value of Systolic, Diastolic, and mean pressure is 10 ~ 360mmHg.
The menu which decide activate of warning sign and message display when the respiration alarm is
on.
1. Move the ▶ mark to select one from RETURN, NIBP-S, NIBP-M, or NIBP-D, and press.
2. Press the key at NIBP-S, and move to LOW, and press again.(The user gets the same result
regardless of the LOW-HIGH, or HIGH-LOW order.)
3. When the color has changed, move it again to select a target value, and press.
4. Press the key at HIGH. When the color has changed, move to the right to select a target value,
and press.
5. Set up or revise the values of NIBP-M and NIBP in the same way as above.
6. With the selection of RETURN, the user can get out of the window.
