Bionet BM5 - Information on the ECG Waveform; Position of 10-Lead; Position of 5-Lead

Rev. 3.1 5.ECG 94
BM5 (CS,CX) User’s Manual
Information on the ECG waveform
When ECG signal is 80bpm T-wave duration is 180ms, and the QT interval is 350ms.
10 Position of 10-Lead
5 Position of 5-Lead
