Bionet BM5 - Introduction; Colors and Standards of Cables

Rev. 3.1 5. ECG 91
BM5 (CS,CX) User’s Manual
5.1 Introduction
It calculates the heart rate with 3 or 5 leads or10 leads ECG signal acquisition and perform the alarm
according to the setting value.
Colors and Standards of Cables
AHA：American Heart Association (U.S.A. Certification)
IEC：International Electro technical Commission (Europe Certification)
3LEAD / 5LEAD
Leadwire
AHA
Color code
AHA
Label
IEC
Color code
IEC
Label
Right arm
White
RA
Red
R
Left arm
Black
LA
Yellow
L
Right leg
Green
RL
Black
N
Left leg
Red
LL
Green
F
V1(precordial)
Brown
V1
White
C1
10LEAD
Leadwire
AHA
Color code
AHA
Label
IEC
Color code
IEC
Label
Right arm
White
RA
Red
R
Left arm
Black
LA
Yellow
L
Right leg
Green
RL
Black
N
Left leg
Red
LL
Green
F
V1(precordial)
Brown(Red)
V1
White(Red)
C1
V2
Brown(Yellow)
V2
White(Yellow)
C2
V3
Brown(Green)
V3
White(Green)
C3
V4
Brown(Blue)
V4
White(Brown)
C4
V5
Brown(Orange)
V5
White(Black)
C5
V6
Brown(Purple)
V6
White(Purple)
C6
