Rev 3.1 10. EtCO2 172
BM5 (CS,CX) User’s Manual
1. Set the Host to the zeroing function.
2. Connect the CAPNOSTAT 5 CO2 Sensor
3. Place the CAPNOSTAT 5 CO2 Sensor onto a clean and dry CO2 adapter that is
exposed to room air and away from all sources of CO2, including the ventilator, the
patient’s breath and your own.
4. Start the adapter zero. The maximum time for a CAPNOSTAT zero is 40 seconds. The
typical time for a zero is 15~20 seconds.
For best result, connect the CAPNOSTAT 5 CO2 Sensor to an adapter and wait 2 minutes
before performing the Adapter Zero procedure.
SETTINGS (Various setting)
Different menus are applied to provide menu and information for handling the EtCO2 module.
ZEROSETTINGS
APNEA
DETECT:
OFF
ALARM
SWEEP
SPEED:
6.25mm/s
WAVEFORM
SCALE:
40mmHg
MAIN
MENU
MODULE
SETUP
MODULE
INFO
MODULE
RESET
PREV
MENU
MAIN
MENU
