Bionet BM5 - ECG Noise and Signal Problems

Rev. 3.1 15. TROUBLE SHOOTING 202
BM5 (CS,CX) User’s Manual
15. TROUBLE SHOOTING
15.1 Noise in ECG
- Gel is dry
- Electrodes does not stick well to skin
The patient’s skin Yes
is extremely dry
No
The electrode is Yes
in poor condition
No
The cable (lead wire) Yes
is disconnected
No
Repair the ECG B/D
Apply ECG gel or water to the area of
contact then use the electrode
Replace the electrodes
(Use CE compatible products)
Replace lead wires
