Rev 3.1 9. IBP 154
BM5 (CS,CX) User’s Manual
List & Description of IBP Measurement Parameter Label
Parameter Window, Scales Menu Window or Alarm Limits Pop-up Menu will appear according
to the Labels.
IBP displays the measuring positions based on 10 labels shown in the below table.
The below table shows the names for each label and the descriptions to be displayed on the
Parameter Window.
Select ‘OTHER’ for a measuring position not in the listed positions.
LABEL
DESCRIPTION
DISPLAY VALUE
ART
Arterial Pressure
- Systolic, Diastolic and Mean
FEM
Femoral Pressure
- Systolic, Diastolic and Mean
PAP
Pulmonary Artery Pressure
- Systolic, Diastolic and Mean
CVP
Central Venous Pressure
- Mean
LAP
Left Arterial Pressure
- Mean
RAP
Right Arterial Pressure
- Mean
ICP
Intracranial Pressure
- Mean
OTHER
Other (IBP1, IBP2)
- Mean
UAP
Umbilical Artery Pressure
- Systolic, Diastolic, and Mean
UVP
Umbilical Venous Pressure
- Mean
