Rev. 3.1 1.BASIC
BM5 (CS,CX) User’s Manual
Word feature menu
The following figure shows the screen where the word sequence menu is activated within the word
sequence correction menu. Here, the cursor moves over the words when the Trim Knob key is
turned in the clockwise direction.
The above figure shows how the cursor moves on the screen. The cursor moves according to the
direction the Trim Knob Key is turned. Press the Trim Knob key if you want to change a letter
currently on the screen.
A █
SET
UNIT
NAME
PREV
MENU
MAIN
MENU
The above figure shows how the cursor is selected to change a letter. Right-hand turning of the Trim
Knob Key makes it possible to select in the order of 0-9,A-Z, and a blank, while left-hand turning
makes the movement in the opposite direction. Once a letter or a number is selected, the screen
comes back to the condition where the same process of selection can be made. One may move to
the menu item in the left of the screen to end the process, which is completed by pressing Trim
Knob Key. After completion, the screen comes back to the earlier picture.
Operation menu
The setup value changes without a selection when the menu is moved.
