Bitzer VARIPACK FMY+6-4 User Manual

CB-110-4 13
5.2 Cable cross-sections and tightening torques
FI size Maximum cable cross-sections and tightening torques
(in Nm)
Control terminals Power terminals Earth connections
mm
2
Nm mm
2
Nm mm
2
Nm
FMY+6-4 1,5 0,5 Pin cable lug up to 6 mm
2
0,8 M4 Ring cable lug 2
FMY+10-4
FMY+14-4
FNY+18-4
FNY+24-4
FNY+30-4
FOY+39-4 Pin cable lug up to 16 mm
2
2
FOY+46-4
FPW+61-4 Pin cable lug up to 35 mm
2
4 M4 Ring cable lug 35 mm
2
4
FPW+72-4
FPW+90-4
FQW+110-4 M10 Ring cable lug 150 mm
2
15 M10 Ring cable lug 150 mm
2
15
FQW+150-4
FQW+180-4
FRW+202-4
FRW+240-4
FRW+302-4
FSW+370-4 M12 Ring cable lug 240 mm
2
60 M12 Ring cable lug 240 mm
2
60
FSW+480-4
FMU+6-4 Pin cable lug up to 6 mm
2
1 Pin cable lug up to 6 mm
2
1
FMU+10-4
FNU+14-4
FNU+18-4
FNU+24-4
FOU+30-4 Pin cable lug up to 16 mm
2
2 Pin cable lug up to 16 mm
2
2
FOU+39-4
FOU+46-4
FPU+61-4 Pin cable lug up to 35 mm
2
4 Pin cable lug up to 35 mm
2
4
FPU+72-4
FPU+90-4
FQU+110-4 M10 Ring cable lug 150 mm
2
12 M8 Ring cable lug 150 mm
2
12
FQU+150-4
FQU+180-4 15 M10 Ring cable lug 150 mm
2
15
FSU+370-4 M12 Ring cable lug 240 mm
2
60 M12 Ring cable lug 240 mm
2
60
FSU+480-4
