Using Videohub Master Control
The destination field shows a lock icon if the destination is
locked.
The lock icon disappears from the destination field when the
destination is unlocked.
Locking and Unlocking Routes
Videohub Master Control can lock and unlock any route on your Videohub. In contrast to Videohub
Smart Control, Videohub Master Control can also unlock any destinations locked by other people using
their computer, iPad or Videohub Smart Control.
To lock a destination using Videohub Master Control:
Step 1. Set the destination and source using whichever method you prefer. Once the route has been
set, Videohub Master Control will return to its idle state.
Step 2. Press the DEST button. The destination field will be highlighted blue on the LCD.
Step 3. If the desired route is not already displayed on the LCD, use the pushbuttons and/or scroll
wheel to find the destination to be locked.
Step 4. Press and hold the gold DEST button until a lock icon appears in the destination field of the LCD.
Step 5. Press DEST again to return Videohub Master Control to its idle state and the destination field
will revert to gray.
To unlock a destination using Videohub Master Control:
Step 1. Press the DEST button. The destination field will highlighted blue on the LCD.
Step 2. If the desired route is not already displayed on the LCD, use the pushbuttons and/or scroll
wheel to find the destination to be unlocked. The destination field will show a lock icon for
the locked destination.
Step 3. Press and hold the gold DEST button until the lock icon disappears from the destination field
of the LCD.
Step 4. Press DEST again to return Videohub Master Control to its idle state and the destination field
will revert to gray.
