113 MT55 Operation & Maintenance Manual
(MT55) MINI TRACK LOADER SPECIFICATIONS (CONT’D)
Hydraulic System
Electrical
Drive System
Capacities
Pump Type Engine driven, gear type
Pump Capacity 45,4 L/min (12 U.S. gpm) @ High Idle
System Relief at Quick Couplers 19900 kpa (199 bar) (2900 psi)
Filter (Hydraulic) Full flow replaceable, 10-micron synthetic media element
Hydraulic Cylinders
Bore Diameter: Lift Cylinder (2)
Tilt Cylinder (2)
Rod Diameter: Lift Cylinder (2)
Tilt Cylinder (2)
Stroke: Lift Cylinder (2)
Tilt Cylinder (1)
Double-acting; tilt cylinders have cushioning feature on dump and rollback
57,2 mm (2.25 in)
76,2 mm (3.00 in)
31,8 mm (1.25 in)
31,8 mm (1.25 in)
359,7 mm (14.16 in)
268,2 mm (10.56 in)
Control Valve 3-Spool, open center type with float detent on lift
Fluid Type Bobcat Fluid, Hydraulic / Hydrostatic
6903117 - (2.5 U.S. gal container)
6903118 - (5 U.S. gal container)
6903119 - (55 U.S. gal container)
Fluid Lines SAE Standard tubelines, hoses and fittings
Hydraulic Function Time:
Raise Lift Arms
Lower Lift Arms
Bucket Dump
Bucket Rollback
2.9 seconds
2.0 seconds
1.6 seconds
1.4 seconds
Starting Aid Glow Plugs
Alternator 12 volt, 40 Amp open frame w/ internal regulator
Battery 12 volt - 530 CCA @ -18°C (0°F)
Starter 12 volt; gear reduction, 2,7 kW (3.62 hp)
Instrumentation Gauges: Hourmeter, Fuel Level, Engine Coolant Tem perature, Voltmeter
W
a
rning lights: Engine Oil Pressure, Hydraulic Oil Temperature
Other: Lights, Opt. / Accessory Switches or Indicators
Drive System Fully hydrostatic, track drive
Transmission Infinitely variable tandem hydrostatic piston pumps, driving two fully reversing
hydrostatic motors
Fuel 26,5 L (7 U.S. gal)
Engine Lubrication and Filter 3,6 L (3.8 qt)
Engine Cooling System 4,73 L (5 qt)
Hydraulic / Hydrostatic Reservoir Only
(Center of Sight Glass) 9,5 L (2.5 U.S. gal)
Hydraulic / Hydrostatic System 20,0 L (5.3 U.S. gal)
